Sel 751A - Table F.13 Logical Device: MET (Metering)

F.21
Date Code 20100129 Instruction Manual SEL-751A Relay
IEC 61850 Communications
Logical Nodes
Table F.13 shows the LN associated with measuring elements defined as
Logical Device MET.
BKR1CSWI1 Pos.Oper.ctlVal CC
BKR1CSWI1 OpOpn.general OC
BKR1CSWI1 OpCls.general CC
Table F.12 Logical Device: PRO (Protection) (Sheet 4 of 4)
Logical Node Status Relay Word Bit Comment
Table F.13 Logical Device: MET (Metering) (Sheet 1 of 3)
Logical Node Measurand Comment
Fundamental Metering
METMMXU1 TotW.mag Three-phase Real Power P Magnitude
a
METMMXU1 TotVAr.mag Three-phase Reactive Power Q Magnitude
a
METMMXU1 TotVA.mag Three-phase Apparent Power S Magnitude
a
METMMXU1 TotPF.mag Three-phase Power Factor
a
METMMXU1 Hz.mag Measured frequency
METMMXU1 PPV.phsAB.cVal.mag AB-phase voltage magnitude when DELTA_Y=D
a
METMMXU1 PPV.phsAB.cVal.ang AB-phase voltage angle when DELTA_Y=D
a
METMMXU1 PPV.phsBC.cVal.mag BC-phase voltage magnitude when DELTA_Y=D
a
METMMXU1 PPV.phsBC.cVal.ang BC-phase voltage angle when DELTA_Y=D
a
METMMXU1 PPV.phsCA.cVal.mag CA-phase voltage magnitude when DELTA_Y=D
a
METMMXU1 PhV.phsA.cVal.mag A-phase voltage magnitude when DELTA_Y=Y.
a
METMMXU1 PhV.phsA.cVal.ang A-phase voltage angle when DELTA_Y=Y
a
METMMXU1 PhV.phsB.cVal.mag B-phase voltage magnitude when DELTA_Y=Y
a
METMMXU1 PhV.phsB.cVal.ang B-phase voltage angle when DELTA_Y=Y
a
METMMXU1 PhV.phsC.cVal.mag C-phase voltage magnitude when DELTA_Y=Y
a
METMMXU1 PhV.phsC.cVal.ang C-phase voltage angle when DELTA_Y=Y
a
METMMXU1 PhV.res.cVal.mag Residual voltage magnitude when DELTA_Y=Y
a
METMMXU1 PhV.res.cVal.ang Residual voltage angle when DELTA_Y=Y
a
METMMXU1 A.phsA.cVal.mag A-phase current magnitude
METMMXU1 A.phsA.cVal.ang A-phase current angle
METMMXU1 A.phsB.cVal.mag B-phase current magnitude
METMMXU1 A.phsB.cVal.ang B-phase current angle
METMMXU1 A.phsC.cVal.mag C-phase current magnitude
METMMXU1 A.phsC.cVal.ang C-phase current angle
METMMXU1 A.neut.cVal.mag Neutral current magnitude
METMMXU1 A.neut.cVal.ang Neutral current angle
METMMXU1 A.res.cVal.mag Residual current magnitude
METMMXU1 A.res.cVal.ang Residual current angle
METMMXU1 W.phsA.mag A-phase real power magnitude
a
METMMXU1 W.phsB.mag B-phase real power magnitude
a
METMMXU1 W.phsC.mag C-phase real power magnitude
a
METMMXU1 VAr.phsA.mag A-phase reactive power magnitude
a
