F.20
SEL-751A Relay Instruction Manual Date Code 20100129
IEC 61850 Communications
Logical Nodes
R4TPFRC4 Op.general 81R4T
P1TPTUV1 Str.general 27P1
P1TPTUV1 Op.general 27P1T
P2TPTUV2 Str.general 27P2
P2TPTUV2 Op.general 27P2T
LOPPTUV3 Str.general LOP
LOPPTUV3 Op.general LOP
P3PTUV4 Str.general 3P27
P3PTUV4 Op.general 3P27
S1TPTUV5 Str.general 27S1
S1TPTUV5 Op.general 27S1T
S2TPTUV6 Str.general 27S2
S2TPTUV6 Op.general 27S2T
P1TPTOV1 Str.general 59P1
P1TPTOV1 Op.general 59P1T
P2TPTOV2 Str.general 59P2
P2TPTOV2 Op.general 59P2T
P3PTOV3 Str.general 3P59
P3PTOV3 Op.general 3P59
S1TPTOV4 Str.general 59S1
S1TPTOV4 Op.general 59S1T
S2TPTOV5 Str.general 59S2
S2TPTOV5 Op.general 59S2T
G1TPTOV6 Str.general 59G1
G1TPTOV6 Op.general 59G1T
G2TPTOV7 Str.general 59G2
G2TPTOV7 Op.general 59G2T
Q1TPTOV8 Str.general 59Q1
Q1TPTOV8 Op.general 59Q1T
Q2TPTOV9 Str.general 59Q2
Q2TPTOV9 Op.general 59Q2T
A55POPF1 Str.general 55A
A55POPF1 Op.general 55A
T55POPF2 Str.general 55T
T55POPF2 Op.general 55T
TRIPPTRC1 Tr.general TRIP
BFR1RBRF1 Str.general BFI
BFR1RBRF1 OpEx.general BFT
BK1XCBR1 Pos.stVal 52A Result of 52A SEL
OGIC setting
BK1XCBR1 OpCnt.stVal INTT Internal Trips Counter
BKR1CSWI1 Pos.stVal 52A Result of 52A SELOGIC setting
Table F.12 Logical Device: PRO (Protection) (Sheet 3 of 4)
Logical Node Status Relay Word Bit Comment
