Sel 751A - Page 563

F.19
Date Code 20100129 Instruction Manual SEL-751A Relay
IEC 61850 Communications
Logical Nodes
NAFPIOC18 Str.general 50NAF
NAFPIOC18 Op.general 50NAF
P1TPTOC1 Str.general 51P1P
P1TPTOC1 Op.general 51P1T
P2TPTOC2 Str.general 51P2P
P2TPTOC2 Op.general 51P2T
N1TPTOC3 Str.general 51N1P
N1TPTOC3 Op.general 51N1T
N2TPTOC4 Str.general 51N2P
N2TPTOC4 Op.general 51N2T
G1TPTOC5 Str.general 51G1P
G1TPTOC5 Op.general 51G1T
G2TPTOC6 Str.general 51G2P
G2TPTOC6 Op.general 51G2T
QTPTOC7 Str.general 51QP
QTPTOC7 Op.general 51QT
ATPTOC8 Str.general 51AP
ATPTOC8 Op.general 51AT
BTPTOC9 Str.general 51BP
BTPTOC9 Op.general 51BT
CTPTOC10 Str.general 51CP
CTPTOC10 Op.general 51CT
D1TPTOF1 Str.general 81D1T
D1TPTOF1 Op.general 81D1T
D2TPTOF2 Str.general 81D2T
D2TPTOF2 Op.general 81D2T
D3TPTOF3 Str.general 81D3T
D3TPTOF3 Op.general 81D3T
D4TPTOF4 Str.general 81D4T
D4TPTOF4 Op.general 81D4T
D5TPTOF5 Str.general 81D5T
D5TPTOF5 Op.general 81D5T
D6TPTOF6 Str.general 81D6T
D6TPTOF6 Op.general 81D6T
R1TPFRC1 Str.general 81R1T
R1TPFRC1 Op.general 81R1T
R2TPFRC2 Str.general 81R2T
R2TPFRC2 Op.general 81R2T
R3TPFRC3 Str.general 81R3T
R3TPFRC3 Op.general 81R3T
R4TPFRC4 Str.general 81R4T
Table F.12 Logical Device: PRO (Protection) (Sheet 2 of 4)
Logical Node Status Relay Word Bit Comment
