7.28
SEL-751A Relay Instruction Manual Date Code 20100129
Communications
SEL ASCII Protocol and Commands
An example response to the GOOSE commands is shown in Figure 7.19.
#>GOOSE <Enter>
GOOSE Transmit Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_751A_2CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-04 4:1 2 20376 50
Data Set: SEL_751A_2CFG/LLN0$DSet13
GOOSE Receive Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_751A_1CFG/LLN0$GO$NewGOOSEMessage5
01-0C-CD-01-00-05 4:0 1 100425 160
Data Set: SEL_751A_1CFG/LLN0$DSet10
SEL_751A_1CFG/LLN0$GO$NewGOOSEMessage3
01-0C-CD-01-00-03 4:0 1 98531 120
Data Set: SEL_751A_1CFG/LLN0$DSet05
SEL_751A_1CFG/LLN0$GO$NewGOOSEMessage2
01-0C-CD-01-00-02 4:0 1 97486 200
Data Set: SEL_751A_1CFG/LLN0$DSet04
SEL_751A_1CFG/LLN0$GO$NewGOOSEMessage1
01-0C-CD-01-00-01 4:0 1 96412 190
Data Set: SEL_751A_1CFG/LLN0$DSet03
SEL_387E_1CFG/LLN0$GO$NewGOOSEMessage5
01-0C-CD-01-00-06 4:0 1 116156 140
Data Set: SEL_387E_1CFG/LLN0$DSet10
SEL_387E_1CFG/LLN0$GO$NewGOOSEMessage4
01-0C-CD-01-00-05 4:0 1 116041 130
Data Set: SEL_387E_1CFG/LLN0$DSet06
SEL_387E_1CFG/LLN0$GO$NewGOOSEMessage2
01-0C-CD-01-00-02 4:0 1 115848 120
Data Set: SEL_387E_1CFG/LLN0$DSet04
SEL_387E_1CFG/LLN0$GO$NewGOOSEMessage1
01-0C-CD-01-00-01 4:0 1 115798 150
Data Set: SEL_387E_1CFG/LLN0$DSet03
=>
Figure 7.19 GOOSE Command Response
GROUP Command
Use the GROUP command (see Table 7.19) to display the active settings
group or try to force an active settings group change.
When you change the active group, the relay responds with a confirmation
prompt:
Are you sure (Y/N)? Answer Y <Enter> to change the active
group. The relay asserts the Relay Word bit SALARM for one second when
you change the active group.
If any of the SEL
OGIC control equations SS1–SS3 are set when you issue the
GROUP n command, the group change will fail. The relay responds:
Command
Unavailable: Active setting group
SELOGIC equations have
priority over the GROUP command
.
Ta b le 7 . 1 9 G R O U P Co m m an d
Command Description Access Level
GROUP Display the active settings group. 1
GROUP n
a
a
Parameter n indicates group numbers 1–3.
Change the active group to Group n.2
