IEC 61850 Communications
IEC 61850 Configuration
➤ 002L (Original Prefixes): This file is recommended for use in
maintaining version 001 logical node names in an SEL-751A
with firmware R102 or later. You may want to select this file so
you can continue using the original logical node names in a
project compatible with newer SEL firmware.
➤ 002 Short LN Prefixes (Default): This file is similar to version
002L, but has logical node prefixes and instances constrained to
7 characters or less. This file is recommended for most
applications, especially in IEC 61850 installations where
logical node names must meet this criterion.
➤ 002 R200 or greater: Constrained Logical Node names as
above, with additional logical nodes made accessible in
SEL-751A R200 or higher firmware. Select this file to enable
access to these additional logical nodes. Note: Using this file
with SEL-751A firmware versions lower than R200 may cause
unexpected behavior.
➤ 002 R300 or greater: Constrained Logical Node names as
above, with additional logical nodes made accessible in
SEL-751A R300 or higher firmware. Select this file to enable
access to these additional logical nodes. Note: Using this file
with SEL-751A firmware versions lower than R300 may cause
unexpected behavior.
CID File Conversion
If you attempt to download a version 001 CID file to a relay with firmware
R102 or later, Architect will detect the incompatibility and offer to convert the
existing file. If you agree,
ACSELERATOR Architect will modify the existing
CID file so that the relay can successfully process it. Note that
ACSELERATOR
Architect will only prompt you to perform this conversion when it recognizes
that the CID file it is trying to download is unsupported. This is done on a per-
file basis. That is, there is no option to do a batch conversion of all CID files in
a project. Also, if you want to preserve any CID file modifications, ensure that
you save the project before exiting
ACSELERATOR Architect. See Tab le F. 7 for
a summary of the logical nodes provided with each ICD file version.
Table F.7 ICD Logical Nodes Summary (Sheet 1 of 4)
Logical
Device
Logical Nodes by ICD Version
Description
Ver 001 and
Ver 002L
Ver 002
Ver 002
R200+
Ver 002
R300+
PRO P1T_PIOC1 P1TPIOC1 P1TPIOC1 P1TPIOC1 Definite-time phase overcurrent ele-
ment 1
PRO P2T_PIOC2 P2TPIOC2 P2TPIOC2 P2TPIOC2 Definite-time phase overcurrent ele-
ment 2
PRO P3T_PIOC3 P3TPIOC3 P3TPIOC3 P3TPIOC3 Definite-time phase overcurrent ele-
ment 3
PRO P4T_PIOC4 P4TPIOC4 P4TPIOC4 P4TPIOC4 Definite-time phase overcurrent ele-
ment 4
PRO N1T_PIOC5 N1TPIOC5 N1TPIOC5 N1TPIOC5 Definite-time neutral overcurrent ele-
ment 1
PRO N2T_PIOC6 N2TPIOC6 N2TPIOC6 N2TPIOC6 Definite-time neutral overcurrent ele-
ment 2
PRO N3T_PIOC7 N3TPIOC7 N3TPIOC7 N3TPIOC7 Definite-time neutral overcurrent ele-
ment 3
