F.13
Date Code 20100129 Instruction Manual SEL-751A Relay
IEC 61850 Communications
IEC 61850 Configuration
PRO N4T_PIOC8 N4TPIOC8 N4TPIOC8 N4TPIOC8 Definite-time neutral overcurrent ele-
ment 4
PRO G1T_PIOC9 G1TPIOC9 G1TPIOC9 G1TPIOC9 Definite-time residual overcurrent
element 1
PRO G2T_PIOC10 G2TPIOC10 G2TPIOC10 G2TPIOC10 Definite-time residual overcurrent
element 2
PRO G3T_PIOC11 G3TPIOC11 G3TPIOC11 G3TPIOC11 Definite-time residual overcurrent
element 3
PRO G4T_PIOC12 G4TPIOC12 G4TPIOC12 G4TPIOC12 Definite-time residual overcurrent
element 4
PRO Q1T_PIOC13 Q1TPIOC13 Q1TPIOC13 Q1TPIOC13 Definite-time negative-sequence
overcurrent element 1
PRO Q2T_PIOC14 Q2TPIOC14 Q2TPIOC14 Q2TPIOC14 Definite-time negative-sequence
overcurrent element 2
PRO Q3T_PIOC15 Q3TPIOC15 Q3TPIOC15 Q3TPIOC15 Definite-time negative-sequence
overcurrent element 3
PRO Q4T_PIOC16 Q4TPIOC16 Q4TPIOC16 Q4TPIOC16 Definite-time negative-sequence
overcurrent element 4
— — — PAFPIOC17 Sample-based phase overcurrent ele-
ment
— — — NAFPIOC18 Sample-based neutral overcurrent
element
PRO P1T_PTOC1 P1TPTOC1 P1TPTOC1 P1TPTOC1 Maximum phase time-overcurrent
element 1
PRO P2T_PTOC2 P2TPTOC2 P2TPTOC2 P2TPTOC2 Maximum phase time-overcurrent
element 2
PRO N1T_PTOC3 N1TPTOC3 N1TPTOC3 N1TPTOC3 Neutral time-overcurrent element 1
PRO N2T_PTOC4 N2TPTOC4 N2TPTOC4 N2TPTOC4 Neutral time-overcurrent element 2
PRO G1T_PTOC5 G1TPTOC5 G1TPTOC5 G1TPTOC5 Residual time-overcurrent element 1
PRO G2T_PTOC6 G2TPTOC6 G2TPTOC6 G2TPTOC6 Residual time-overcurrent element 2
PRO QT_PTOC7 QTPTOC7 QTPTOC7 QTPTOC7 Negative-sequence time-overcurrent
element
PRO AT_PTOC8 ATPTOC8 ATPTOC8 ATPTOC8 Phase A time-overcurrent element
PRO BT_PTOC9 BTPTOC9 BTPTOC9 BTPTOC9 Phase B time-overcurrent element
PRO CT_PTOC10 CTPTOC10 CTPTOC10 CTPTOC10 Phase C time-overcurrent element
PRO D1T_PTOF1 D1TPTOF1 D1TPTOF1 D1TPTOF1 Definite-time over- and underfre-
quency element 1
PRO D2T_PTOF2 D2TPTOF2 D2TPTOF2 D2TPTOF2 Definite-time over- and underfre-
quency element 2
PRO D3T_PTOF3 D3TPTOF3 D3TPTOF3 D3TPTOF3 Definite-time over- and underfre-
quency element 3
PRO D4T_PTOF4 D4TPTOF4 D4TPTOF4 D4TPTOF4 Definite-time over- and underfre-
quency element 4
— — — D5TPTOF5 Definite-time over- and underfre-
quency element 5
Table F.7 ICD Logical Nodes Summary (Sheet 2 of 4)
Logical
Device
Logical Nodes by ICD Version
Description
Ver 001 and
Ver 002L
Ver 002
Ver 002
R200+
Ver 002
R300+
