F.14
SEL-751A Relay Instruction Manual Date Code 20100129
IEC 61850 Communications
IEC 61850 Configuration
— — — D6TPTOF6 Definite-time over- and underfre-
quency element 6
— — — R1TPFRC1 Rate of change of frequency
element 1
— — — R2TPFRC2 Rate of change of frequency
element 2
— — — R3TPFRC3 Rate of change of frequency
element 3
— — — R4TPFRC4 Rate of change of frequency element
4
PRO P1T_PTUV1 P1TPTUV1 P1TPTUV1 P1TPTUV1 Phase undervoltage element 1
PRO P2T_PTUV2 P2TPTUV2 P2TPTUV2 P2TPTUV2 Phase undervoltage element 2
PRO LOP_PTUV3 LOPPTUV3 LOPPTUV3 LOPPTUV3 Loss of potential
— — — P3PTUV4 27A1 * 27B1 * 27C1
— — — S1TPTUV5 VS channel under voltage element 1
— — — S2TPTUV6 VS channel under voltage element 2
PRO P1T_PTOV1 P1TPTOV1 P1TPTOV1 P1TPTOV1 Phase overvoltage element 1
PRO P2T_PTOV2 P2TPTOV2 P2TPTOV2 P2TPTOV2 Phase overvoltage element 2
— — — P3PTOV3 59A1 * 59B1 * 59C1
— — — S1TPTOV4 VS channel over voltage element 1
— — — S2TPTOV5 VS channel over voltage element 2
— — — G1TPTOV6 Zero-Sequence Instantaneous Over-
voltage element 1
— — — G2TPTOV7 Zero-Sequence instantaneous over-
voltage element 2
— — — Q1TPTOV8 Negative-sequence instantaneous
overvoltage element 1
— — — Q2TPTOV9 Negative-sequence instantaneous
overvoltage element 2
PRO A55_POPF1 A55POPF1 A55POPF1 A55POPF1 Power factor alarm
PRO T55_POPF2 T55POPF2 T55POPF2 T55POPF2 Power factor trip
PRO TRIP_PTRC1 TRIPPTRC1 TRIPPTRC1 TRIPPTRC1 Output of trip logic
PRO ULTRIP_PTRC2 ULTRIPPTRC2 — — Unlatch trip (auto reset) from SEL-
OGIC control equation (not supported
in firmware versions R200 or higher)
— — — BFR1RBRF1 Breaker Failure Element
PRO BK1_XCBR1 BK1XCBR1 BK1XCBR1 BK1XCBR1 Asserts when SEL
OGIC control equa-
tion 52A is logical 1
PRO BKR1_CSWI1 BKR1CSWI1 BKR1CSWI1 BKR1CSWI1 OPEN/CLOSE command
MET MET_MMXU1 METMMXU1 METMMXU1 METMMXU1 Measured values (currents, voltages,
power) (modified in firmware ver-
sions R200 or higher)
MET THERM_MTHR1 THERMMTHR1 THERMMTHR1 THERMMTHR1 Measured values (RTD temperatures)
Table F.7 ICD Logical Nodes Summary (Sheet 3 of 4)
Logical
Device
Logical Nodes by ICD Version
Description
Ver 001 and
Ver 002L
Ver 002
Ver 002
R200+
Ver 002
R300+
