SET.40
of 68
SEL-751A Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
Class for Binary Event Data (0–3) ECLASSB2 :=
Class for Counter Event Data (0–3)
ECLASSC2 :=
Class for Analog Event Data (0–3)
ECLASSA2 :=
Currents Scaling Decimal Places (0–3)
DECPLA2 :=
Voltages Scaling Decimal Places (0–3)
DECPLV2 :=
Misc Data Scaling Decimal Places (0–3)
DECPLM2 :=
Amps Reporting Deadband Counts (0–32767)
(HiddenifECLASSA2:=0)
ANADBA2 :=
Volts Reporting Deadband Counts (0–32767)
(HiddenifECLASSA2:=0)
ANADBV2 :=
Misc Data Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA2 := 0 and ECLASSC2 := 0)
ANADBM2 :=
Minutes for Request Interval (I, M, 1–32767)
TIMERQ2 :=
Seconds to Select/Operate Time-Out (0.0–30.0)
STIMEO2 :=
Seconds to send Data Link Heartbeat (0–7200)
(HiddenifDNPTR2:=UDP)
DNPINA2 :=
Event Message Confirm Time-Out (1–50 sec))
ETIMEO2 :=
Enable Unsolicited Reporting (Y, N)
(Hidden if ECLASSA2 := 0, ECLASSB2 := 0, ECLASSC2 := 0, and
ECLASSV2 := 0)
UNSOL2 :=
Enable Unsolicited Reporting at Power-Up (Y, N)
(HiddenifUNSOL2:=N)
PUNSOL2 :=
Number of Events to Transmit On (1–200)
(HiddenifUNSOL2:=N)
NUMEVE2 :=
Oldest Event to Tx On (0.0–99999.0 sec)
(HiddenifUNSOL2:=N)
AGEEVE2 :=
Unsolicited Message Max Retry Attempts (2–10)
(HiddenifUNSOL2:=N)
URETRY2 :=
Unsolicited Message Offline Time-Out (1–5000 sec)
(HiddenifUNSOL2:=N)
UTIMEO2 :=
Session 3
All Session 3 settings are Hidden if EDNP < 3.
IP Address {zzz.yyy.xxx.www} (15 characters)
DNPIP3 :=
Transport Protocol (UDP, TCP)
DNPTR3 :=
UDP Response Port (REQ, 1–65534)
DNPUDP3 :=
DNP Address to Report to (0–65519)
REPADR3 :=
DNP Map (1–3)
DNPMAP3 :=
Analog Input Default Variation (1–6)
DVARAI3 :=
Class for Binary Event Data (0–3)
ECLASSB3 :=
