SEL-751A Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
RMB1 Dropout Debounce Messages (1–8) RMB1DO :=
RMB2 Pickup Debounce Messages (1–8)
RMB2PU :=
RMB2 Dropout Debounce Messages (1–8)
RMB2DO :=
RMB3 Pickup Debounce Messages (1–8)
RMB3PU :=
RMB3 Dropout Debounce Messages (1–8)
RMB3DO :=
RMB4 Pickup Debounce Messages (1–8)
RMB4PU :=
RMB4 Dropout Debounce Messages (1–8)
RMB4DO :=
RMB5 Pickup Debounce Messages (1–8)
RMB5PU :=
RMB5 Dropout Debounce Messages (1–8)
RMB5DO :=
RMB6 Pickup Debounce Messages (1–8)
RMB6PU :=
RMB6 Dropout Debounce Messages (1–8)
RMB6DO :=
RMB7 Pickup Debounce Messages (1–8)
RMB7PU :=
RMB7 Dropout Debounce Messages (1–8)
RMB7DO :=
RMB8 Pickup Debounce Messages (1–8)
RMB8PU :=
RMB8 Dropout Debounce Messages (1–8)
RMB8DO :=
PORT 4 (EIA-232/485 Port or DeviceNet Port in Slot C)
(Hidden If Option Not Included)
PROTOCOL (SEL, DNP, MOD, DNET, EVMSG, PMU, MBA,
MBB, MB8A, MB8B, MBTA, MBTB)
PROTO :=
Interface Select (Hidden if PROTO := DNET)
COMM INTERFACE (232, 485) COMMINF :=
Communications
SPEED (300–38400 bps) (Hidden if PROTO := DNET) SPEED :=
DATA BITS (7, 8 bits)
(Hidden if PROTO := DNP, MOD, PMU, EVMSG, MB_, or DNET)
BITS :=
PARITY (O, E, N)
(Hidden if PROTO := DNET, EVMSG, PMU, or MB_)
PARITY :=
STOP BITS (1, 2 bits)
(Hidden if PROTO := MOD, EVMSG, MB_, or DNET)
STOP :=
PORT TIME-OUT (0–30 min)
(Hidden if PROTO := MOD, EVMSG, MB_, PMU, or DNET)
T_OUT :=
HDWR HANDSHAKING (Y, N)
(Hidden if COMMINF := 485 or PROTO := MOD, DNP, EVMSG,
MB_, or DNET)
RTSCTS :=
SEND AUTOMESSAGE (Y, N)
(Hidden if PROTO := DNP, MOD, EVMSG, MB_, PMU, or DNET)
AUTO :=
