Sel 751A - Page 299

Date _______________
Date Code 20100129 Instruction Manual SEL-751A Relay
SET.49
of 68
SEL-751A Settings Sheets
Front-Panel Settings (SET F Command)
RMB6 Pickup Debounce Messages (1–8) RMB6PU :=
RMB6 Dropout Debounce Messages (1–8)
RMB6DO :=
RMB7 Pickup Debounce Messages (1–8)
RMB7PU :=
RMB7 Dropout Debounce Messages (1–8)
RMB7DO :=
RMB8 Pickup Debounce Messages (1–8)
RMB8PU :=
RMB8 Dropout Debounce Messages (1–8)
RMB8DO :=
Front-Panel Settings (SET F Command)
General
DISPLY PTS ENABL (N,1–32) EDP :=
LOCAL BITS ENABL (N,1–32)
ELB :=
LCD TIMEOUT (OFF,1–30 min)
FP_TO :=
LCD CONTRAST (1–8)
FP_CONT :=
FP AUTOMESSAGES (OVERRIDE, ROTATING)
FP_AUTO :=
CLOSE RESET LEDS (Y, N)
RSTLED :=
Target LED
TRIP LATCH T_LED (Y, N) T01LEDL :=
LED1 EQUATION (SEL
OGIC) T01_LED :=
TRIP LATCH T_LED (Y, N)
T02LEDL :=
LED2 EQUATION (SEL
OGIC) T02_LED :=
TRIP LATCH T_LED (Y, N)
T03LEDL :=
LED3 EQUATION (SEL
OGIC) T03_LED :=
TRIP LATCH T_LED (Y, N)
T04LEDL :=
LED4 EQUATION (SEL
OGIC) T04_LED :=
TRIP LATCH T_LED (Y, N)
T05LEDL :=
LED5 EQUATION (SEL
OGIC) T05_LED :=
TRIP LATCH T_LED (Y, N)
T06LEDL :=
LED6 EQUATION (SEL
OGIC) T06_LED :=
PB1A_LED EQUATION (SEL
OGIC) PB1A_LED :=
PB1B_LED EQUATION (SEL
OGIC) PB1B_LED :=
PB2A_LED EQUATION (SEL
OGIC) PB2A_LED :=
PB2B_LED EQUATION (SEL
OGIC) PB2B_LED :=
PB3A_LED EQUATION (SEL
OGIC) PB3A_LED :=
