D.22
SEL-751A Relay Instruction Manual Date Code 20100129
DNP3 Communications
DNP3 Documentation
21 9 32-Bit Frozen Counter Without Flag 1 129
21 10 16-Bit Frozen Counter Without Flag 1 129
21 11 32-Bit Frozen Delta Counter Without Flag
21 12 16-Bit Frozen Delta Counter Without Flag
22 0 Counter Change Event—All Variations 1 6, 7, 8
22 1 32-Bit Counter Change Event
Without Time
1 6, 7, 8 129 17, 28
22 2
e
16-Bit Counter Change Event
Without Time
1 6, 7, 8 129, 130 17, 28
22 3 32-Bit Delta Counter Change Event
Without Time
22 4 16-Bit Delta Counter Change Event
Without Time
22 5 32-Bit Counter Change Event With Time 1 6, 7, 8 129 17, 28
22 6 16-Bit Counter Change Event With Time 1 6, 7, 8 129 17, 28
22 7 32-Bit Delta Counter Change Event
With Time
22 8 16-Bit Delta Counter Change Event
With Time
23 0 Frozen Counter Event—All Variations
23 1 32-Bit Frozen Counter Event Without Time
23 2 16-Bit Frozen Counter Event Without Time
23 3 32-Bit Frozen Delta Counter Event
Without Time
23 4 16-Bit Frozen Delta Counter Event
Without Time
23 5 32-Bit Frozen Counter Event With Time
23 6 16-Bit Frozen Counter Event With Time
23 7 32-Bit Delta Counter Change Event
With Time
23 8 16-Bit Delta Counter Change Event
With Time
30 0 Analog Input—All Variations 1 0, 1, 6, 7, 8, 17, 28
30 1 32-Bit Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 2 16-Bit Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 3 32-Bit Analog Input Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 4
e
16-Bit Analog Input Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 5 Short Floating Point Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 6 Long Floating Point Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
31 0 Frozen Analog Input—All Variations
31 1 32-Bit Frozen Analog Input
31 2 16-Bit Frozen Analog Input
31 3 32-Bit Frozen Analog Input With Time of
Freeze
Table D.11 SEL-751A DNP Object List (Sheet 2 of 5)
Obj. Var. Description
Request
a
Response
b
Funct. Codes
c
Qual. Codes
d
Funct. Codes
c
Qual. Codes
d
