E.32
SEL-751A Relay Instruction Manual Date Code 20100129
Modbus RTU Communications
Modbus Register Map
382 (R/W) NEU TOC TIM DL1 5 1500 150 0.01 482
383 (R/W) NEU EM RST DLAY1 0 1 0 483
0 = N
1 = Y
384 (R/W) NEUT CONST TIME1 sec 0 100 0 0.01 484
385 (R/W) NEU MIN RESP T1 sec 0 100 0 0.01 485
386 (R/W) NEUT TOC L2 EN 0 1 0 486
0 = N
1 = Y
387 (R/W) NEU TOC TRIP L2 A 10 1600 120 0.01 487
388 (R/W) NEU TOC TRIP L2 mA 1 1600 100 0.1 488
389 (R/W) NEUT TOC CURVE2 0 9 2 1 489
0 = U1
1 = U2
2 = U3
3 = U4
4 = U5
5 = C1
6 = C2
7 = C3
8 = C4
9 = C5
390 (R/W) NEU TOC TIM DL2 5 1500 150 0.01 490
391 (R/W) NEU EM RST DLAY2 0 1 0 491
0 = N
1 = Y
392 (R/W) NEUT CONST TIME2 sec 0 100 0 0.01 492
393 (R/W) NEU MIN RESP T2 sec 0 100 0 0.01 493
Residual Time Overcurrent
394 (R/W) RES TOC L1 EN 0 1 1 494
0 = N
1 = Y
395 (R/W) RES TOC TRIP L1 A 10 1600 10 0.01 495
396 (R/W) RES TOC CURVE1 0 9 2 1 496
0 = U1
1 = U2
2 = U3
3 = U4
4 = U5
5 = C1
6 = C2
7 = C3
8 = C4
9 = C5
397 (R/W) RES TOC TIM DL1 5 1500 150 0.01 497
398 (R/W) RES EM RST DLAY1 0 1 0 498
0 = N
1 = Y
399 (R/W) RES CONST TIME1 sec 0 100 0 0.01 499
400 (R/W) RES MIN RESP T1 sec 0 100 0 0.01 500
401 (R/W) RES TOC L2 EN 0 1 1 501
0 = N
1 = Y
Table E.32 Modbus Register Map
a
(Sheet 7 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
