E.49
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
957 (R) RTD3 MN DAY dd 1 31 1 1 1057
958 (R) RTD3 MN DAY mm 1 12 1 1 1058
959 (R) RTD3 MN DAY yy 2000 9999 2000 1 1059
960 (R) RTD4 MAX degC –32768 32767 0 1 1060
961 (R) RTD4 MX TIM ss 0 5999 0 0.01 1061
962 (R) RTD4 MX TIM mm 0 59 0 1 1062
963 (R) RTD4 MX TIM hh 0 23 0 1 1063
964 (R) RTD4 MX DAY dd 1 31 1 1 1064
965 (R) RTD4 MX DAY mm 1 12 1 1 1065
966 (R) RTD4 MX DAY yy 2000 9999 2000 1 1066
967 (R) RTD4 MIN degC –32768 32767 0 1 1067
968 (R) RTD4 MN TIM ss 0 5999 0 0.01 1068
969 (R) RTD4 MN TIM mm 0 59 0 1 1069
970 (R) RTD4 MN TIM hh 0 23 0 1 1070
971 (R) RTD4 MN DAY dd 1 31 1 1 1071
972 (R) RTD4 MN DAY mm 1 12 1 1 1072
973 (R) RTD4 MN DAY yy 2000 9999 2000 1 1073
974 (R) RTD5 MAX degC –32768 32767 0 1 1074
975 (R) RTD5 MX TIM ss 0 5999 0 0.01 1075
976 (R) RTD5 MX TIM mm 0 59 0 1 1076
977 (R) RTD5 MX TIM hh 0 23 0 1 1077
978 (R) RTD5 MX DAY dd 1 31 1 1 1078
979 (R) RTD5 MX DAY mm 1 12 1 1 1079
980 (R) RTD5 MX DAY yy 2000 9999 2000 1 1080
981 (R) RTD5 MIN degC –32768 32767 0 1 1081
982 (R) RTD5 MN TIM ss 0 5999 0 0.01 1082
983 (R) RTD5 MN TIM mm 0 59 0 1 1083
984 (R) RTD5 MN TIM hh 0 23 0 1 1084
985 (R) RTD5 MN DAY dd 1 31 1 1 1085
986 (R) RTD5 MN DAY mm 1 12 1 1 1086
987 (R) RTD5 MN DAY yy 2000 9999 2000 1 1087
988 (R) RTD6 MAX degC –32768 32767 0 1 1088
989 (R) RTD6 MX TIM ss 0 5999 0 0.01 1089
990 (R) RTD6 MX TIM mm 0 59 0 1 1090
991 (R) RTD6 MX TIM hh 0 23 0 1 1091
992 (R) RTD6 MX DAY dd 1 31 1 1 1092
993 (R) RTD6 MX DAY mm 1 12 1 1 1093
994 (R) RTD6 MX DAY yy 2000 9999 2000 1 1094
995 (R) RTD6 MIN degC –32768 32767 0 1 1095
996 (R) RTD6 MN TIM ss 0 5999 0 0.01 1096
997 (R) RTD6 MN TIM mm 0 59 0 1 1097
998 (R) RTD6 MN TIM hh 0 23 0 1 1098
999 (R) RTD6 MN DAY dd 1 31 1 1 1099
Table E.32 Modbus Register Map
a
(Sheet 24 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
