Sel 751A - Page 527

E.65
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Modbus Register Map
1655 (R) IC EXT kA 0 65535 0 1 1755
1656 (R) A WEAR % 0 10000 0 0.01 1756
1657 (R) B WEAR % 0 10000 0 0.01 1757
1658 (R) C WEAR % 0 10000 0 0.01 1758
1659 (R) BRKR RST TIM ss 0 5999 0 0.01 1759
1660 (R) BRKR RST TIM mm 0 59 0 1 1760
1661 (R) BRKR RST TIM hh 0 23 0 1 1761
1662 (R) BRKR RST DAT dd 1 31 1 1 1762
1663 (R) BRKR RST DAT mm 1 12 1 1 1763
1664 (R) BRKR RST DAT yy 2000 9999 2000 1 1764
1665-1666 (R) Reserved
c
0 0 0 1765-1766
VS Maximum/Minimum Data
1667 (R) VS MAX 0 65535 0 1 1767
1668 (R) VS MAX TIME ss 0 5999 0 0.01 1768
1669 (R) VS MAX TIME mm 0 59 0 1 1769
1670 (R) VS MAX TIME hh 0 23 0 1 1770
1671 (R) VS MAX DAY dd 1 31 1 1 1771
1672 (R) VS MAX DAY mm 1 12 1 1 1772
1673 (R) VS MAX DAY yy 2000 9999 2000 1 1773
1674 (R) VS MIN 0 65535 0 1 1774
1675 (R) VS MIN TIME ss 0 5999 0 0.01 1775
1676 (R) VS MIN TIME mm 0 59 0 1 1776
1677 (R) VS MIN TIME hh 0 23 0 1 1777
1678 (R) VS MIN DAY dd 1 31 1 1 1778
1679 (R) VS MIN DAY mm 1 12 1 1 1779
1680 (R) VS MIN DAY yy 2000 9999 2000 1 1780
1681-1688 (R) (R) Reserved
c
0 0 0 1781-1788
Demand Data
1689 (R) IA DEMAND 0 65535 0 1 1789
1690 (R) IB DEMAND 0 65535 0 1 1790
1691 (R) IC DEMAND 0 65535 0 1 1791
1692 (R) IG DEMAND 0 65535 0 1 1792
1693 (R) 3I2 DEMAND 0 65535 0 1 1793
1694 (R) IA PEAK DEMAND 0 65535 0 1 1794
1695 (R) IB PEAK DEMAND 0 65535 0 1 1795
1696 (R) IC PEAK DEMAND 0 65535 0 1 1796
1697 (R) IG PEAK DEMAND 0 65535 0 1 1797
1698 (R) 3I2 PEAK DEMAND 0 65535 0 1 1798
1699 (R) PEAKD RST TIM ss 0 5999 0 0.01 1799
1700 (R) PEAKD RST TIM mm 0 59 0 1 1800
1701 (R) PEAKD RST TIM hh 0 23 0 1 1801
1702 (R) PEAKD RST DAT dd 1 31 1 1 1802
Table E.32 Modbus Register Map
a
(Sheet 40 of 56)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Facto r
DeviceNet
Parameter
Numbers
