J.9
Date Code 20100129 Instruction Manual SEL-751A Relay
Relay Word Bits
Definitions
DNAUXn DeviceNet/Modbus AUXn assert bit, where n = 1 to 8. 30
DNAUXn DeviceNet/Modbus AUXn assert bit, where n = 9 to 11. 31
DSABLSET Settings changes not allowed from the front-panel interface—when asserted. 22
DST Daylight Savings Time (Synchrophasors). 112
DSTP Daylight Savings Time Pending (Synchrophasors). 112
ENABLED Relay Enabled. 0
ER Event report trigger SEL
OGIC control equation (see Table 4.64). 29
FAULT Fault indication. Asserts when the SEL
OGIC control equation FAULT result in a logical 1. 13
FREQTRK Asserts when relay is tracking frequency. 29
GFLT Ground fault (50G1 + 50G2 + 50G3 + 50G4 + 51G1 + 51G2) 117
GNDEM Zero-Sequence Current Demand Pickup 109
HALARM Hardware alarm (see Self-Test on page 10.12). 22
IN101 Contact input. 17
IN102 Contact input. 17
INnnn Contact input nnn, where nnn = 301 to 304 (available only with optional I/O module). 18
INnnn Contact input nnn, where nnn = 401 to 404 (available only with optional I/O module). 19
INnnn Contact input nnn, where nnn = 501 to 504 (available only with optional I/O module). 20
IRIGOK IRIG-B input OK. 13
LB01 to LB08 Local Bit n asserted, where n = 1 to 8. 35
LB09 to LB16 Local Bit n asserted, where n = 9 to 16. 36
LB17 to LB24 Local Bit n asserted, where n = 17 to 24. 37
LB25 to LB32 Local Bit n asserted, where n = 25 to 32. 38
LBOKA Channel A, looped back ok. 92
LBOKB Channel B, looped back ok. 92
LINKA Assert if Ethernet Port A detects link. 13
LINKB Assert if Ethernet Port B detects link 13
LINKFAIL Failure of active Ethernet port link 27
LOP Loss-of-Potential logic asserted (see Figure 4.26). 14
LPSEC Direction of the upcoming leap second. During the time that LPSECP is asserted, if LPSEC is
asserted, the upcoming leap second is deleted; otherwise, the leap second is added (synchropha-
sors)
112
LPSECP Leap second pending (synchrophasors) 112
LTnn Latch Bit nn asserted, where nn = 01 to 08 (see Figure 4.44). 51
LTnn Latch Bit nn asserted, where nn = 09 to 16 (see Figure 4.44). 52
LTnn Latch Bit nn asserted, where nn = 17 to 24 (see Figure 4.44). 53
LTnn Latch Bit nn asserted, where nn = 25 to 32 (see Figure 4.44). 54
OC Open command—asserts when serial port command OPEN or front-panel or Modbus/DeviceNet
OPEN
command is issued (see Table 4.25 and Figure 4.29).
29
OPTMN Open interval timer is timing. 27
ORED50T Logical OR of all the instantaneous overcurrent elements tripped outputs (see Figure 4.1). 1
ORED51T Logical OR of all the time-overcurrent elements tripped outputs (see Figure 4.3 through
Figure 4.7).
1
Table J.2 Relay Word Bit Definitions for the SEL-751A (Sheet 6 of 11)
Bit Definition Row
