K.4
SEL-751A Relay Instruction Manual Date Code 20100129
Analog Quantities
IGMN Calculated residual minimum current A primary xxxx
VABMX A-to-B phase maximum voltage V primary xxxx
VBCMX B-to-C phase maximum voltage V primary xxxx
VCAMX C-to-A phase maximum voltage V primary xxxx
VAMX A-phase maximum voltage V primary xxxx
VBMX B-phase maximum voltage V primary xxxx
VCMX C-phase maximum voltage V primary xxxx
VSMX Vsync maximum voltage V primary xxxx
VABMN A-to-B phase minimum voltage V primary xxxx
VBCMN B-to-C phase minimum voltage V primary xxxx
VCAMN C-to-A phase minimum voltage V primary xxxx
VAMN A-phase minimum voltage V primary xxxx
VBMN B-phase minimum voltage V primary xxxx
VCMN C-phase minimum voltage V primary xxxx
VSMN Vsync minimum voltage V primary xxxx
KVA3PMX 3-phase maximum apparent power kVA primary xxxx
KW3PMX 3-phase maximum real power kW primary xxxx
KVAR3PMX 3-phase maximum reactive power kVAR primaryxxxx
KVA3PMN 3-phase minimum apparent power kVA primary xxxx
KW3PMN 3-phase minimum real power kW primary xxxx
KVAR3PMN 3-phase minimum reactive power kVAR primaryxxxx
FREQMX Maximum frequency Hz xxxx
FREQMN Minimum frequency Hz xxxx
RTD1MX to
RTD12MX
RTD1 maximum to RTD12 maximum °C xxxx
RTD1MN to
RTD12MN
RTD1 minimum to RTD12 minimum °C xxxx
AI301MX to
AI308MX
Analog transducer input 301–308 maximum
a
xxxx
AI301MN to
AI308MN
Analog transducer input 301–308 minimum
a
xxxx
AI401MX to
AI408MX
Analog transducer input 401–408 maximum
a
xxxx
AI401MN to
AI408MN
Analog transducer input 401–408 minimum
a
xxxx
AI501MX to
AI508MX
Analog transducer input 501–508 maximum
a
xxxx
AI501MN to
AI508MN
Analog Transducer Input 501–508 minimum
a
xxxx
Table K.1 Analog Quantities (Sheet 4 of 6)
Label Description Units
Display Points SELOGIC Load Profile DNP Fast Meter
