Addr. Parameter C Setting Options Default Setting
Breaker settings
_:2311:112 General:Current thresh.
CB open
1 A @ 100 Irated 0.030 A to 10.000 A 0.100 A
5 A @ 100 Irated 0.15 A to 50.00 A 0.50 A
1 A @ 50 Irated 0.030 A to 10.000 A 0.100 A
5 A @ 50 Irated 0.15 A to 50.00 A 0.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.100 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 0.500 A
_:2311:136 General:Op. mode BFP
•
unbalancing
•
I> query
unbalancing
Information List
No. Information Data Class
(Type)
Type
Circuit break.
_:4261:500 Circuit break.:>Ready SPS I
_:4261:501 Circuit break.:>Acquisition blocking SPS I
_:4261:502 Circuit break.:>Reset switch statist. SPS I
_:4261:504 Circuit break.:>Reset AcqBlk&Subst SPS I
_:4261:503 Circuit break.:External health ENS I
_:4261:53 Circuit break.:Health ENS O
_:4261:58 Circuit break.:Position DPC C
_:4261:300 Circuit break.:Trip/open cmd. SPS O
_:4261:301 Circuit break.:Close command SPS O
_:4261:302 Circuit break.:Command active SPS O
_:4261:303 Circuit break.:Definitive trip SPS O
_:4261:304 Circuit break.:Alarm suppression SPS O
_:4261:306 Circuit break.:Op.ct. INS O
_:4261:307 Circuit break.:ΣI Brk. BCR O
_:4261:308 Circuit break.:ΣIA Brk. BCR O
_:4261:309 Circuit break.:ΣIB Brk. BCR O
_:4261:310 Circuit break.:ΣIC Brk. BCR O
_:4261:311 Circuit break.:Break.-current phs A MV O
_:4261:312 Circuit break.:Break.-current phs B MV O
_:4261:313 Circuit break.:Break.-current phs C MV O
_:4261:317 Circuit break.:Tripping current 3I0/IN MV O
_:4261:314 Circuit break.:Break. voltage phs A MV O
_:4261:315 Circuit break.:Break. voltage phs B MV O
_:4261:316 Circuit break.:Break. voltage phs C MV O
_:4261:322 Circuit break.:CB open hours INS O
_:4261:323 Circuit break.:Operating hours INS O
5.7.5
Function-Group Types
5.7 Function-Group Type Circuit Breaker
280 SIPROTEC 5, Overcurrent Protection, Manual
C53000-G5040-C017-8, Edition 07.2017
