With the parameter Pickup delay you set whether pickup of the stage is to be delayed or not. If the tran-
sient cycle of the ground fault occurrence should not be evaluated, set a delay of 100 ms, for example.
Parameter: Operate delay
•
Default setting (_:6) Operate delay = 0.30 s
The Operate delay parameter determines the time during which the pickup conditions must be met to
issue the operate indication. The operate indication is issued when this time expires.
Settings
Addr. Parameter C Setting Options Default Setting
3I0> #
_:1 3I0> #:Mode
•
off
•
on
•
test
off
_:2 3I0> #:Operate & flt.rec.
blocked
•
no
•
yes
no
_:27 3I0> #:Blk. w. inrush
curr. detect.
•
no
•
yes
no
_:8 3I0> #:Method of meas-
urement
•
fundamental comp.
•
RMS value
fundamental
comp.
_:3 3I0> #:Threshold 1 A @ 100 Irated 0.030 A to 35.000 A 0.050 A
5 A @ 100 Irated 0.15 A to 175.00 A 0.25 A
1 A @ 50 Irated 0.030 A to 35.000 A 0.050 A
5 A @ 50 Irated 0.15 A to 175.00 A 0.25 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.050 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 0.250 A
_:102 3I0> #:Pickup delay 0.00 s to 60.00 s 0.00 s
_:6 3I0> #:Operate delay 0.00 s to 60.00 s 0.30 s
Information List
No.
Information Data Class
(Type)
Type
3I0> #
_:81 3I0> #:>Block stage SPS I
_:500 3I0> #:>Block delay & op. SPS I
_:54 3I0> #:Inactive SPS O
_:52 3I0> #:Behavior ENS O
_:53 3I0> #:Health ENS O
_:60 3I0> #:Inrush blocks operate ACT O
_:55 3I0> #:Pickup ACD O
_:56 3I0> #:Operate delay expired ACT O
_:57 3I0> #:Operate ACT O
Non-Directional Y0 Stage
Description
In the Directional sensitive ground-fault detection function, the Non-directional Y0 stage also works on
demand.
6.15.11.3
6.15.11.4
6.15.12
6.15.12.1
Protection and Automation Functions
6.15 Sensitive Ground-Fault Detection
SIPROTEC 5, Overcurrent Protection, Manual 615
C53000-G5040-C017-8, Edition 07.2017
