Addr. Parameter C Setting Options Default Setting
_:16951:101 V-seal-in 1:State of V-
seal-in
•
off
•
on
off
_:16951:102 V-seal-in 1:V-seal-in
threshold
0.300 V to 175.000 V 80.019 V
_:16951:104 V-seal-in 1:Duration of V-
seal-in time
0.10 s to 60.00 s 4.00 s
Information List
No. Information Data Class
(Type)
Type
V-seal-in 1
_:16951:81 V-seal-in 1:>Block stage SPS I
_:16951:500 V-seal-in 1:>Block V-seal-in SPS I
_:16951:52 V-seal-in 1:Behavior ENS O
_:16951:53 V-seal-in 1:Health ENS O
_:16951:54 V-seal-in 1:Inactive SPS O
_:16951:55 V-seal-in 1:Pickup ACD O
_:16951:300 V-seal-in 1:Pickup I>+V-seal-in SPS O
_:16951:56 V-seal-in 1:Operate delay expired ACT O
_:16951:57 V-seal-in 1:Operate ACT O
6.4.5.4
Protection and Automation Functions
6.4 Voltage-Dependent Overcurrent Protection, Phases
372 SIPROTEC 5, Overcurrent Protection, Manual
C53000-G5040-C017-8, Edition 07.2017
