Setting Relative Time Reference
²
Reference the display of log entries, if needed, to the real time of a specific entry. In this way, you deter-
mine a relative time for all other indications. The real-time stamps of events remain unaffected.
Displaying Indications
Displayed indications in DIGSI 5 and on the on-site operation panel are supplemented with the following infor-
mation:
Table 3-1 Overview of Additional Information
Indications in DIGSI 5 Information Device Display Information
Log for operational indications and
log for user-defined indications
Time stamp (date and time),
Relative time,
Entry number,
Function structure,
Name,
Value,
Quality,
Cause,
Number
Time stamp (date and time),
Function structure,
Name,
Value
Log for fault indications Time stamp (date and time),
Relative time,
Fault number,
Entry number,
Function structure,
Name,
Value,
Quality,
Cause,
Number
Time stamp (date and time),
Fault number,
Value
Log for motor-starting indications Time stamp (date and time),
Motor-starting time,
Starting current,
Starting voltage,
Starting duration
Time stamp (date and time),
Function structure,
Name,
Value
Log for ground-fault indications Time stamp (date and time),
Relative time,
Fault number,
Entry number,
Function structure,
Name,
Value,
Indication number,
Quality,
Cause,
Number
Time stamp (date and time),
Fault number,
Value
3.1.4
System Functions
3.1 Indications
SIPROTEC 5, Overcurrent Protection, Manual 65
C53000-G5040-C017-8, Edition 07.2017
