VPN Configuration
19.3 Configuring Routing Profiles
SCALANCE W1750D UI
324 Configuration Manual, 02/2018, C79000-G8976-C451-02
netmask, but ensure that the gateway is the primary controller IP for one route and the
backup controller IP for the second route.
–
—The default metric value is 15. Specify a metric value for the datapath route.
When two routes or more routes with the same network destination are available for
data forwarding, the route with the least metric value takes preference.
4. Repeat step 3 to create the required number of routing profiles.
5. Click
.
6. Click
.
(scalance)(config)# routing-profile
(scalance)(Routing-profile)# route <destination> <mask> <gateway> {<metric>}
(scalance)(Routing-profile)# end
(scalance)# commit apply
Note
Routing profile is primarily used for AP
-VPN scenarios, to control which traffic should flow
between the master AP and the VPN tunnel, and which traffic should flow outside of the
tunnel.
