ClearPass Guest Setup

34.3 Troubleshooting

SCALANCE W1750D UI

Configuration Manual, 02/2018, C79000-G8976-C451-02

527

34.3

Troubleshooting

Table 34- 1 Troubleshooting

Problem

Solution

Limiting devices has no effect.

Ensure IPv6 is disabled.

Apple Macintosh running Mountain Lion can use AirPlay but iOS

devices cannot.

Ensure IPv6 is disabled.
