Voice and Video
23.1 Wi-Fi Multimedia Traffic Management
SCALANCE W1750D UI
Configuration Manual, 02/2018, C79000-G8976-C451-02
377
3. Specify a percentage value for the following WMM access categories in the
corresponding
text box. You can allocate a higher bandwidth for voice and video
traffic than that for other types of traffic based on the network profile.
–
—Allocates bandwidth for background traffic such as file downloads
or print jobs.
–
—Allocates bandwidth or best effort traffic such as traffic from legacy
devices or traffic from applications or devices that do not support QoS.
–
—Allocates bandwidth for video traffic generated from video streaming.
–
—Allocates bandwidth for voice traffic generated from the incoming and
outgoing voice communication.
4. Click
and complete the configuration as required
Configuring WMM for wireless clients:
(scalance)(config)# wlan ssid-profile <name>
(scalance)(SSID Profile <name>)# wmm-background-share <share>
(scalance)(SSID Profile <name>)# wmm-best-effort-share <share>
(scalance)(SSID Profile <name>)# wmm-video-share <share>
(scalance)(SSID Profile <name>)# wmm-voice-share <share>
(scalance)(SSID Profile <name>)# end
(scalance)# commit apply
Mapping WMM ACs and DSCP Tags
The IEEE 802.11e standard defines the mapping between WMM ACs and Differentiated
Services Code Point (DSCP) tags. You can customize the mapping values between WMM
ACs and DSCP tags to prioritize various traffic types and apply these changes to a WMM-
enabled SSID profile.
DSCP classifies packets based on network policies and rules. The following table shows the
default WMM AC to DSCP mappings and the recommended WMM AC to DSCP mappings.
Table 23- 2
WMM AC-DSCP Mapping
Background
16
Best effort
Video
Voice
