SCALANCE W User Interface
6.2 Main Window
SCALANCE W1750D UI
Configuration Manual, 02/2018, C79000-G8976-C451-02
67
Graph Name
Description
Monitoring Procedure
Frames The Frames graph shows the In and Out frame rate
per second of the client for the last 15 minutes. It also
shows data for the Retry In and Retry Out frames.
• Outgoing frames — Outgoing frame traffic is dis-
played in green. It is shown above the median line.
• Incoming frames — Incoming frame traffic is dis-
played in blue. It is shown below the median line.
• Retry Out — Retries for the outgoing frames are
displayed above the median line in black .
• Retry In — Retries for the incoming frames are
displayed below the median line in red.
To see an enlarged view, click the graph. The enlarged
view provides Last, Minimum, Maximum, and Average
statistics for the In, Out, Retries In, and Retries Out
frames.
To see the exact frames at a particular time, move the
cursor over the graph line.
To monitor the In and Out frame rate per sec-
ond and retry frames for the In and Out traffic,
for the last 15 minutes:
1. Log in to the SCALANCE W UI. The Virtual
Controller view is displayed. This is the
default view.
2. On the
Clients
tab, click the IP address of
the client for which you want to monitor the
frames.
3. Study the Frames graph in the RF Trends
pane. For example, the graph shows 4.0
frames per second for the client at 12:27
hours.
Speed The Speed graph shows the data transfer speed for
the client. Data transfer is measured in Mbps.
To see an enlarged view, click the graph. The enlarged
view shows Last, Minimum, Maximum, and Average
statistics of the client for the last 15 minutes.
To see the exact speed at a particular time, move the
cursor over the graph line.
To monitor the speed for the client for the last
15 minutes:
1. Log in to the SCALANCE W UI. The Virtual
Controller view is displayed. This is the
default view.
2. On the
Clients
tab, click the IP address of
the client for which you want to monitor the
speed.
3. Study the Speed graph in the RF Trends
pane. For example, the graph shows that
the data transfer speed at 12:26 hours is
240 Mbps.
Throughput The Throughput Graph shows the throughput of the
selected client for the last 15 minutes.
• Outgoing traffic — Throughput for the outgoing
traffic is displayed in green. It is shown above the
median line.
• Incoming traffic — Throughput for the incoming
traffic is displayed in blue. It is shown below the
median line.
To see an enlarged view, click the graph. The enlarged
view shows Last, Minimum, Maximum, and Average
statistics for the incoming and outgoing traffic through-
put of the client for the last 15 minutes.
To see the exact throughput at a particular time, move
the cursor over the graph line.
To monitor the errors for the client for the last
15 minutes:
1. Log in to the SCALANCE W UI. The Virtual
Controller view is displayed. This is the
default view.
2. In the
Clients
tab, click the IP address of the
client for which you want to monitor the
throughput.
3. Study the Throughput graph in the RF
Trends pane. For example, the graph shows
1.0 Kbps outgoing traffic throughput for the
client at 12:30 hours.
Client View—RF Trends Graphs and Monitoring Procedures
