Captive Portal for Guest Access
13.5 Configuring External Captive Portal for Guest Network
SCALANCE W1750D UI
Configuration Manual, 02/2018, C79000-G8976-C451-02
181
To configure security settings for guest users of the wired profile:
(scalance)(config)# wired-port-profile <name>
(scalance)(wired ap profile <name>)# type <Guest>
(scalance)(wired ap profile <name>)# captive-portal{<type>[exclude-uplink
<types>]|external [exclude-uplink <types>| profile <name>[exclude-uplink <types>]]}
(scalance)(wired ap profile <name>)# mac-authentication
(scalance)(wired ap profile <name>)# end
(scalance)# commit apply
13.5.4
External Captive Portal Redirect Parameters
If the external captive portal redirection is enabled on a network profile, AP sends an HTTP
response with the redirect URL to display the splash page and enforce captive portal
authentication by clients. The HTTP response from the AP includes the following
parameters:
Table 13- 1 External Captive Portal Redirect Parameters
Parameter
Example Value
Description
cmd
login
Type of operation
mac 34:02:86:c6:d2:3e Client MAC address
essid
guest-ecp-109
ESSID
ip
192.0.2.0
Client IP address
apname
9c:1c:12:cb:a2:90
AP host name
apmac
9c:1c:12:cb:a2:90
AP MAC address
vcname
scalance-C8:1D:DA"
VC name
url
http://www.google.com/
original URL
13.5.5
Configuring External Captive Portal Authentication Using ClearPass Guest
You can configure SCALANCE W to point to ClearPass Guest as an external captive portal
server. With this configuration, the user authentication is performed by matching a string in
the server response and that in the RADIUS server (either ClearPass Guest or a different
RADIUS server).
