AP-VPN Deployment Scenarios

35.1 Scenario 1 - IPsec: Single Datacenter Deployment with No Redundancy

SCALANCE W1750D UI

534 Configuration Manual, 02/2018, C79000-G8976-C451-02

Configuration Steps

CLI Commands

UI Procedure

7. Create access rule for wired and

wireless authentication. In this exam-

ple, the rule permits all traffic.

For wired profile:

(scalance)(config)# wlan access-rule wired-

port (scalance)(Access Rule "wired-port")#

rule any any match any any any permit

For WLAN SSID:

(scalance)(config)# wlan access-rule wire-

less-ssid

(scalance)(Access Rule "wireless-ssid")#

rule any any match any any any permit

See Configuring ACL Rules

for Network Services

NOTE: Ensure that you execute the commit apply command in the SCALANCE W CLI before saving the configuration and

propagating changes across the AP cluster.

AP-Connected Switch Configuration

Client VLANs defined in this example must be opened on the upstream switches in multiple

AP deployments, as client traffic from the slave to the master is tagged with the client VLAN.

Datacenter Configuration

For information on controller configuration, see Configuring a Controller for AP-VPN

Operations. Ensure that the upstream router is configured with a static route pointing to the

controller for the L3 VLAN.
