SCALANCE W User Interface
6.2 Main Window
SCALANCE W1750D UI
Configuration Manual, 02/2018, C79000-G8976-C451-02
65
4 Noise Displays the noise floor details for the APs. Noise is measured in decibels/meter. Depend-
ing on the noise floor, the color of the lines on the Noise icon changes in the following
order:
• Green — Noise floor is more than 87 dBm.
• Orange — Noise floor is between 80 dBm and 87 dBm.
• Red — Noise floor is less than 80 dBm.
To view the noise floor graph of an AP, click the Noise icon next to the AP in the Noise
5 Errors Displays the errors for the APs. Depending on the errors, color of the lines on the Errors
icon changes in the following order:
• Green — Errors are less than 5000 frames per second.
• Orange — Errors are between 5000 and 10,000 frames per second.
• Red — Errors are more than 10000 frames per second.
To view the errors graph of an AP, click the Errors icon next to the AP in the Errors col-
Contents of the Info Section in the SCALANCE W Main Window
