Chapter 22 DCU Setup (DCU)
1008
Serial Port Settings (Serial Port Assign Menu)
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) 1. Maximum Open Delay: maximum time required to open a file
2. Maximum Cueup Delay: maximum time required to cue up a file
3. Play After Cueup Delay: delay time from the cued-up state to begin playback
4. Play After Open Next Delay: delay time from the Open Next state to begin playback
5
Turn the knob to set the disk recorder response speed.
6
Press [Set].
This confirms the setting.
7
Repeat steps 4 to 6 as required to make the settings for other items.
Making detailed settings for a disk recorder (video disk
communications protocol)
1
In the <DCU Select> group of the DCU >Serial Port Assign menu, select
the target for the setting (DCU1 or DCU2).
2
Using any of the following methods, select the serial port connected to the
disk recorder for which you want to make settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) The range of setting values depends on the DCU port setting. (When the MKS-2700 is
connected, select 2 for the slot and a value in the range 1 to 6 for the port.)
3
Press [Port Setting].
The DCU >Serial Port Assign >DDR VDCP Setting menu appears.
At the top of the status area, the relevant serial port, slot number, protocol,
serial port name, SCU number, and disk recorder type appear.
Knob Parameter Adjustment Setting values
1 Item No Item selection
1 to 4
a)
Knob Parameter Adjustment Setting values
2 Setting Response speed setting 0 to 255
Knob Parameter Adjustment Setting values
1 Port No Serial port
1 and upwards
a)
