893Cross-Point Settings (Xpt Assign Menu)
Chapter 19 Control Panel Setup (Panel)
Cross-Point Settings (Xpt Assign Menu)
To carry out the cross-point settings, use the Panel >Xpt Assign menu.
To display the Xpt Assign menu
In the Engineering Setup menu, select VF2 ‘Panel’ and HF2 ‘Xpt Assign.’
The status area shows a list of “cross-point assign tables” to use for the M/E
banks, PGM/PST bank, and various buses.
The following functions are available here.
• Xpt Assign: For each control block or bus, display and set the assignments
to the main table and tables 1 to 14. You can also carry out settings to link
switcher signal selection to the audio mixer.
• Main, V/K Pair Assign: Make cross-point settings for the main table.
– Assign video/key sources for button numbers 1 to 128.
– For each table, specify whether the rightmost cross-point button in each
row is used as a shift button, and the operation mode when it is used as a
shift button.
– For the [SHIFT] button in the cross-point control block and for each table,
select the mode in which this is a shift button dedicated to the source name
displays, or the mode in which it is a shift button for all buses.
– Disable cross-point buttons to work.
• Mixer Xpt Assign: Assign audio mixer cross-points to cross-point buttons
in the main table.
• Table Button Assign: Create tables 1 to 14 in the same way as the main
table.
• Src Name: Set source names of up to 16 characters.
• LCD Color: Set the LCD color for source name display.
• Table Copy: Copy table contents from the main table to tables 1 to 14 or
between tables 1 to 14 (it is not possible to copy tables 1 to 14 to the main
table).
• Name Export: This function sends the source name and destination name to
the S-Bus.
Creating Cross-Point Assign Tables
As cross-point assign tables, you can create a “main” table and up to 14 other
tables (table 1 to table 14). However, you can only carry out assignment of the
video and key combinations in the main table.
