945Settings for Switcher Configuration (Config Menu)
Chapter 20 Switcher Setup (Switcher)
Link: Follow the key on/off setting.
On: Key is always on.
Off: Key is always off.
Setting User Regions
Note
If you change the user region settings, the previously stored snapshot data and
keyframe effect data can no longer be used.
1
In the Switcher >Config menu, press [User1-8 Config].
The User1-8 Config menu appears. The status area shows the region names
and assigned user region numbers.
2
Using any of the following methods, select the region you want to set.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
3
In the <User Region Assign> group, select the user region you want to
assign. If you do not want to assign a user region, select [No Assign].
4
Repeat steps 2 and 3 as required to make the settings for other regions.
5
To confirm the setting, press [Execute]. To cancel the setting and return to
the original state, press [Clear] without pressing [Execute].
When you press [Execute], a confirmation message appears.
6
Press [Yes].
This assigns a region to a user region.
Assigning PGM/PST Logically to an M/E
1
In the Switcher >Config menu, press [Logical M/E Assign].
Knob Parameter Adjustment Setting values
1 Region Region selection 1 and upwards
To Next Page
