Sony DVS-9000 System - Data Saved by [Initial Status Define]

1045Data Saved by [Setup Define] and [Initial Status Define]
Appendix (Volume 3)
Data Saved by [Initial Status Define]
Type Menu number Menu path Saved data
Included in
Panel
— — Setting data and LCD displays for the
following panel buttons
• Key Control Block:
Delegation buttons, [AUTO DELEG]
• Numeric Keypad Control Block:
Mode selection buttons, [TC], [RCALL],
[STORE]
• Menu Control Block:
User preference buttons assigned for
Plug-in Editor Enbl and System
Manager Enbl functions
• [SUB MENU SITE]
• Utility/Shotbox Control Block:
[BANK1] to [BANK4], memory recall
button
• Downstream Key Control Block:
[DSK1] to [DSK4], [K-SS], key source
name display/key snapshot buttons
• CCP-9000:
AUX delegation buttons, bank selection
buttons, mode selection buttons, [EDIT
ENBL], key row delegation buttons
3211 Misc >Enable >Port
Enable >System Manager
All data relating to System Manager
menu
3212 Misc >Enable >Plug-In
Editor
All data relating to Plug-In Editor menu
6351 Snapshot >Key Snapshot
>Attribute
Settings of <Recall Mode> group
Included in
Switcher
(Same as
data saved in
Snapshots)
a)
— — • For each M/E, setting data relating to
the following:
cross-points, transitions, Key1 to Key4
(including settings in the independent
key transition control block), wipes,
DME wipes, video processing
• Color backgrounds 1/2
• Frame memory
• AUX bus (including video processing
settings)
• Monitor bus
3213 Misc >Enable >Side Flags All data relating to Side Flags menu
3211 Misc >Enable >Port
Enable
Setting data for <Switcher> group
Included in
DME
4100 DME >Status Three-dimensional transformation data
4111 DME >Edge >Border/
Crop
All data relating to Border/Crop menu
