329AUX Menu Operations
Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
AUX Menu Operations
AUX Bus Settings
Making video process settings for an AUX bus
1 In the Aux/Mon >Aux Bus menu, using any of the following methods,
select the AUX bus to which the settings apply.
• Directly press the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob to make the setting.
2 Press [Video Process], turning it on.
3 Adjust the following parameters.
To return adjustment values to their defaults, press [Unity].
Knob Parameter Adjustment Setting values
1 AUX Bus AUX bus selection 1 to 48
Knob Parameter Adjustment Setting values
1 Video Gain Video signal gain –200.00 to +200.00
2 Y Gain Luminance signal gain –200.00 to +200.00
3 C Gain Chrominance signal gain –200.00 to +200.00
4 Hue Delay Hue delay –180.00 to +180.00
5 Black Level Black level –7.31 to +109.59
