124
Color Matte Settings
Chapter 3 Signal Selection and Transitions
Color Matte Settings
You can specify the color matte by luminance, saturation, and hue values.
Notes
• This transition type is not available for an independent key transition.
• In the multi-program mode, you can use a preset color mix only when
selecting the background for the next transition.
One-stroke mode and one-time mode
• You can make a setting such that a preset color mix is carried out in a single
transition. This is called “one-stroke mode.”
When the bus fixed mode is selected with a Setup menu setting, a preset color
mix is always carried out in the one-stroke mode.
• You can also make a setting such that when a preset color mix is completed,
the next transition switches to the previous transition type automatically.
This is called “one-time mode.”
When only the background is changed
Preset color mix (changing background only)
Current video Color matte New video
