875Overall Control Panel Settings (Config Menu)
Chapter 19 Control Panel Setup (Panel)
On: The lower M/E bank is non-shifted, and the higher M/E bank is
shifted.
Off: The lower M/E bank is shifted, and the higher M/E bank is non-
shifted.
Assigning the Key Delegation in the Downstream Key
Control Block (MKS-8032 DSK Fader Module, Option)
As an example, to assign key 4 of the M/E-1 bank to key delegation button 1
of the downstream key control block 1, use the following procedure.
1
In the Panel >Config menu, press the [DSK Fader Assign].
The DSK Fader Assign menu appears.
2
Directly press on the indications in the status area, to select the
downstream key control block for which you want to make the setting, and
select the key delegation.
Here, press on the intersection of the “1st Module” column and “Key1
Assign” row.
3
In the <M/E Select> group, select the bank of the key you want to assign.
Here, select [M/E-1] as an example.
4
In the <Key Link Select> group, select the key you want to assign.
Here, select [Key4] as an example.
5
To disable the fader lever of the selected downstream key control block,
select [Disable] in the <Fader Assign> group.
To enable the fader lever, select one of the following in the <Fader
Assign> group, determine the key to which the fader lever operation
applies.
All: Key selected with one of the key delegation buttons
Key1: Key assigned to key delegation button 1 ([DSK1] button)
Key2: Key assigned to key delegation button 2 ([DSK2] button)
Key3: Key assigned to key delegation button 3 ([DSK3] button)
Key4: Key assigned to key delegation button 4 ([DSK4] button)
To Next Page
