Still Image Operations
Chapter 7 Frame Memory
4
When you selected a pattern key or external key, if required press [Key
Invert] in the Still >Composite menu to invert the key.
Image Output
There are two functions related to image output: the reposition function for
moving the output image, and the lock function for fixing the output image.
Moving the output image (reposition function)
For up to two channels of FM1 to FM8 (one from FM1, FM3, FM5 and FM7
and the other from FM2, FM4, FM6 and FM8), you can move the output image
with respect to the screen. The area of the screen around the image that has
been moved is filled with black. There are two ways of carrying out this
repositioning.
Normal mode: Movement in the horizontal direction is in two-pixel
increments.
Black and white mode: Movement in the horizontal direction is in one-pixel
increments, and for each pixel moved the color is inverted.
Note
It is not possible to save an image moved with the reposition function directly
to frame memory.
1
In the Frame Memory menu, select VF3 ‘Reposition/Lock’ and HF1
‘Reposition.’
The Reposition menu appears. In this menu, you can also enable the V/K
mode (see page 278).
2
In the frame memory selection area, select the FM output (see page 277).
3
In the <Reposition> group, select the movement mode.
Normal: Move in normal mode.
Black&White: Move in black & white mode.
4
With the knobs, adjust the parameters to move the image.
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
