Chapter 13 Keyframe Effects
658
Creating and Editing Keyframes
Transition Mode Settings for User Programmable DME
To create an effect for user programmable DME, it is necessary to set the
transition mode.
Setting the transition mode
1 In the Key Frame menu, select HF4 ‘DME User PGM.’
The DME User PGM menu appears.
2 In the <Transition Mode> group, select the transition mode according to
the DME wipe action.
Single: select single transition mode.
Flip/Tumble: select the flip/tumble transition mode.
Dual: select dual transition mode.
P in P: select picture-in-picture mode.
Compress: select compress mode.
Frame I/O: select frame in-out transition mode.
Frame I/O H: select frame in-out transition mode in the horizontal
direction.
Frame I/O V: select frame in-out transition mode in the vertical direction.
For details of creating an effect for user programmable DME, see
“Creating User Programmable DME Patterns” in Chapter 6 (Volume 1).
Note
Which DME channel is selected as the reference region (lit green) in the
numeric keypad control block is reflected in the <Transition Mode> group
display.
