843Selecting the State After Powering On (Start Up Menu)
Chapter 18 System Setup (System)
Saving and Recalling Setup Data
Concept of saving and recalling setup data
Updating the switcher or control panel setup data saves the updated setup data
in RAM in each device.
• In Resume mode (see page 842), even if devices are reset or powered off, the
data is preserved in RAM, and recalled when the power is turned back on.
Note
The Resume mode cannot be used for DMEs and DCUs.
• In Custom mode (see page 842), the user-defined settings (user setup data)
saved in non-volatile memory or factory default setup data held in ROM in
Hard disk / memory card
User setup data
Load Save
File menu:
[Load]
File menu:
[Save]
Current setup data
(If in Resume mode, settings data is saved.)
Store
In Custom mode, power on
or reset
Initialize
User setup data Factory default setup data
Setup menu:
[Setup Define]
Setup
menu:
[All Clear]
RAM
ROM Non-volatile memory
To Next Page
