281Still Image Operations
Chapter 7 Frame Memory
Setting a mask
Masks can be set separately for frame memory source buses 1 and 2. To apply
a mask to the signal selected on frame memory source bus 1, for example, use
the following procedure in the Still >Freeze/Store menu.
1
Press [Box Mask] turning it on.
2
Use the knobs to adjust the following parameters.
3
To link the masks on frame memory source buses 1 and 2, press [Mask
Link], turning it on.
Recalling Still Images
You can recall an image file saved in memory, and allocate to any of the FM1
to FM8 outputs.
Recalling a still image
To recall a still image file saved in memory using the thumbnails, and assign it
to an FM output, use the following procedure.
1
In the Frame Memory menu, select VF1 ‘Still’ and HF1 ‘Recall.’
The Recall menu appears.
• When [Pair] is on, only pair files (pairs of main file and sub file) are
displayed.
Knob Parameter Adjustment Setting values
1 Top Top position –100.00 to +100.00
2 Left Left position –100.00 to +100.00
3 Right Right position –100.00 to +100.00
4 Bottom Bottom position –100.00 to +100.00
To Next Page
