Chapter 19 Control Panel Setup (Panel)
874
Overall Control Panel Settings (Config Menu)
Assigning Two M/E Banks to One M/E Bank
1 In the Panel >Config menu, select the M/E bank for which you want to
make the setting.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) Depends on the center control panel configuration. When the bank closest to the operator
(the 4th row of a 4-M/E system) is selected, [Dual M/E Assign] is disabled.
For example, if the furthest bank from you is assigned to M/E-1, and you
want no shift button operation for the bank, select 1 (1st Row) for Bank.
2 Press [Dual M/E Assign].
This assigns the furthest M/E bank from you to the unshifted (shifted)
cross-points and the M/E bank in front of it to the shifted (unshifted) cross-
points. For fader lever operations, only the M/E bank closer to you is
enabled.
The shift/non-shift assignment is set by [Dual M/E Xpt Swap]. For more
details, see the next section, “Interchanging shifted and non-shifted
operations for a dual M/E.”
To return to the original assignment
Interchange the bank order (see page 873).
Interchanging shifted and non-shifted operations for a dual M/E
1 In the Panel >Config menu, select the M/E bank for which the dual M/E
setting is made.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) Depends on the center control panel configuration.
2 Press [Dual M/E Xpt Swap], toggling it on or off.
Knob Parameter Adjustment Setting values
1 Bank Selection of position of bank for
which you want to make the setting
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Bank Bank to be selected for dual
M/E setting
1 to 4
a)
