369DME Wipe Pattern List

Appendix (Volume 1)

DME Wipe Pattern List

DME Wipe Patterns Available in One-Channel Mode

Slide

Split

1001 1002 1003 1004

1005 1006 1007 1008

1011 1012 1013
