923Interfacing With External Devices (Device Interface Menu)
Chapter 19 Control Panel Setup (Panel)
Carrying out level settings
To set the low level and high level, first set the trigger type to “Level,” then use
the following procedure.
1
In the Panel >Device Interface menu, select the action to be set, and press
[H/L Set].
The H/L Set menu appears.
2
Using any of the following methods, select the settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
3
To apply the selection made in step 2 when the input is the GPI high level,
press [H Set]. To apply the selection made in step 2 when the input is low,
press [L Set].
This confirms the setting, which appears in the status area.
Making Control Panel GPI Output Settings
1
In the Panel >Device Interface menu, press [GPI Output].
The GPI Output menu appears.
2
Using any of the following methods, select the settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
3
In the <Trigger Type> group, select the trigger polarity.
(Rising Edge): The trigger causes the relay contacts to be open-
circuit or drives the output high, and holds this state for the
specified pulse width.
Knob Parameter Adjustment Setting values
1 No Signal format/screen
aspect ratio selection
1 and upwards
Knob Parameter Adjustment Setting values
1 Port Port selection 1 to 8
To Next Page
