983Settings Relating to Signal Outputs (Output Menu)
Chapter 21 DME Setup (DME)
Settings Relating to Signal Outputs (Output
Menu)
To make settings relating to DME output signals, display the DME >Output
menu.
To display the Output menu
In the Engineering Setup menu, select VF4 ‘DME’ and HF3 ‘Output.’
These settings are possible only when the DME is an MVE-9000 or SDI-
interfaced MVE-8000A.
The following functions are available here.
• Monitor Output: Set the signals output from the four monitor output
connectors.
• Clip Adjust: Adjust the clip levels of DME1 and DME2 outputs.
Adjusting the Monitor Output
When the MVE-8000A/MVE-9000 is connected through SDI interface, you
can adjust both DME1 and DME2 output video clip levels.
Use the following procedure. (DME 1 is taken by way of example.)
1 In the <DME1(Ch1-Ch4)> group of the DME >Output menu, press [Clip
Adjust], turning it on.
2 Set the following parameters.
To return the setting to the default value
In the DME >Output menu, press [Default].
Knob Parameter Adjustment Setting values
1 White Clip White clip adjustment 90.00 to 109.02
2 Dark Clip Dark clip adjustment −6.85 to +10.00
3 Chroma Clip Chroma clip adjustment 90.00 to 113.17
