Chapter 21 DME Setup (DME)
982
Settings Relating to Signal Inputs (Input Menu)
1
In the DME >Input menu, press [TBC Center].
The TBC Center menu appears.
The status area shows the TBC center position values for DME1, DME 2,
and external input signals.
Note
The TBC center position values for external input signals are shown only
when an SDI-interfaced MVE-9000 is used.
2
Using any of the following methods, select the input number for which you
want to set the TBC center position.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
3
In the <Video/Key> group (when an SDI-interfaced MVE-8000A/9000 is
used) or the <External Video> group (when an SDI-interfaced MVE-9000
is used), press the desired button, and set the TBC center position to 0H,
0.5H, or 1H.
Knob Parameter Adjustment Setting values
1 No Input number selection 1 to 8
To Next Page
