511DME Special Effect Operations
Chapter 11 DME Operations
To set the partition position
1
Press [Position], turning it on.
2
Set the following parameters.
Mirror settings
You can choose to reflect in the directions left to right, right to left, bottom to
top, top to bottom, or any combination of directions. You can also set the
position of the border between original and reflections.
To apply the Mirror effect
With the Mirror menu displayed, press [Left to Right], [Right to Left], [Top to
Bottom], or [Bottom to Top] to set the reflection method (multiple selections
possible).
Left to Right: Reflect left side on right.
Right to Left: Reflect right side on left.
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Transition H Degree of transition in horizontal
direction
0.000 to 100.000
2 Random H Degree of randomness in distance
moved by blocks in horizontal
direction
0.00 to 100.00
3 Skew H Degree of skew in horizontal direction 0.00 to 100.00
4 Width H Horizontal width of partition 0.00 to 100.00
5 Angle Angle of partition line –8.000 to +8.000
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Transition V Degree of transition in vertical
direction
0.000 to 100.000
2 Random V Degree of randomness in distance
moved by blocks in vertical direction
0.00 to 100.00
3 Skew V Degree of skew in vertical direction 0.00 to 100.00
4 Width V Vertical width of partition 0.00 to 100.00
5 Angle Angle of partition line –8.000 to +8.000
Knob Parameter Adjustment Setting values
1 H Horizontal partition position –5.000 to +5.000
2 V Vertical partition position –5.000 to +5.000
