Chapter 11 DME Operations
556
DME Special Effect Operations
Edge Soft: The Edge Soft effect is applied to the key signal only. The video
signal does not change.
Shadow, Flex Shadow, Combine Shadow: The key signal density changes.
The video signal does not change.
Fade: The key signal changes according to depth data. The video signal does
not change.
Key Density: The key signal density changes. The video signal does not
change.
Invert Settings
Inverts the input video signal and/or key signal horizontally or vertically. You
can make separate settings for the front and back.
Applying the Invert effect
1
In the DME menu, select VF6 ‘Input/Output’ and HF2 ‘Video/Key.’
The Video/Key menu appears.
2
In the <Front> group (to invert front signals) or the <Back> (to invert back
signals), press the following buttons, turning them on.
H Invert: Invert video and key signals horizontally.
V Invert: Invert video and key signals vertically.
Key Density Settings
You can adjust the key density for the key signal input to the DME.
Setting the key density
1
In the DME menu, select VF6 ‘Input/Output’ and HF2 ‘Video/Key.’
The Video/Key menu appears.
2
Press [Key Density], turning it on.
This enables the key density function, and you can now use the knobs to
adjust the parameters.
3
Set the following parameter.
To Next Page
