Chapter 11 DME Operations
496
DME Special Effect Operations
Nonlinear Effect Settings
You can add a variety of effects, including effects that change the shape of the
image as a whole.
1
In the DME menu, select VF4 ‘Non Linear’ and HF1 ‘Type.’
A menu for selecting the various effects appears.
2
Display the menu for the effect that you want to apply by pressing its
button.
The effect displayed is enabled.
3
Make the settings for the selected effect.
Notes
• It is not possible to apply two or more nonlinear effects at the same time.
Turning any nonlinear effect on automatically turns all other nonlinear
effects off.
• The Flex Shadow function cannot be enabled when any of the nonlinear
effects Page Turn, Roll, Cylinder, and Sphere is enabled.
However, the Flex Shadow function is not supported on the MVE-
8000A.
To turn an effect off
In the setting menu, press the button for the effect name, turning it off, or in the
Type menu press [OFF] in the lower right part of the window.
Wave settings
There are two modes: H&V and Size. You can set the size and frequency of the
waves, the wave form, the amount of wave movement, and the range. In H&V
mode, you can also set the wave angle.
To apply the Wave effect
With the Wave menu displayed, use the following procedure.
1
In the <Mode> group, select the wave modulation mode.
H&V: Modulate vertically and horizontally without changing the size of
the image. This mode allows waves to be created in both the vertical
and horizontal directions at the same time.
Size: Create waves by reducing and expanding the image. This mode
allows waves to be created in one direction only.
To Next Page
