203Basic Procedure for Wipe Settings
Chapter 5 Wipes
Note
When Flash Rate is set to 0.00, you cannot change the pattern. In this state,
adjusting H Size or V Size has no effect on the pattern.
For details of a pattern mix, see the next section.
For details of applying pattern modifiers, see “Setting Wipe Modifiers”
(page 208).
Pattern Mix
You can create a new pattern by combining two selected patterns (main and
“sub”).
Note
It is not possible to apply a pattern mix to an independent key transition.
Types of pattern mix
There are four ways in which patterns can be combined in a pattern mix, as
follows.
Mix: The effect of the sub pattern is applied to the main pattern, modifying the
outline or nature of the main pattern.
Positive NAM (+Nam): Creates a pattern with an outline which contains all
points within the outlines of either of the main pattern and the sub pattern.
Negative NAM (–Nam): Creates a pattern with an outline which contains all
points within the outlines of both of the main pattern and the sub pattern.
