Settings Relating to Keys, Wipes, Frame
Memory and Color Correction (Key/Wipe/
FM/CCR Menu)
For settings relating to keys, wipes, frame memory and Color Correction, use
the Switcher >Key/Wipe/FM/CCR menu.
To display the Key/Wipe/FM/CCR menu
In the Engineering Setup menu, select VF3 ‘Switcher’ and HF5 ‘Key/Wipe/
FM/CCR.’
The status area shows the key memory settings, mask and border processing
order, key priority, cross-point hold, pattern limit transition, and wipe edge
settings for each of the M/E and PGM/PST banks.
The following functions are available here.
• Key Memory: Set the key memory operation mode for each of the M/E and
PGM/PST banks.
• Video Proc Memory: Enable or disable video process memory.
• Show Key: Enable or disable show key for edit preview, M/E and P/P Pvw/
K-Pvw.
• Key Auto Drop: For each M/E or PGM/PST bank, specify a key to be turned
off automatically when you press a cross-point button for the bus to be output
as the background.
• Mask/Border Process: Set the processing order of masks and borders for
each M/E or PGM/PST bank.
• Key Priority: Set the key priority operation mode for each of the M/E and
PGM/PST banks. In DSK mode, the key priority is fixed.
• Xpt Hold mode: Set the operation mode for the cross-point hold button
provided on the key bus for each of the M/E and PGM/PST banks.
• Pattern Limit Transition: Set the operation mode when the pattern limit is
released for each of the M/E and PGM/PST banks.
• Wipe Edge Default: Adjust the wipe edge softness for each of the M/E and
PGM/PST banks.
• FM Auto Store: Switch on or off the function to automatically attach a name
and save in frame memory.
Switching Video Process Memory On or Off
In the Switcher >Key/Wipe/FM/CCR menu, press [Video Proc Memory],
turning it on.
