Chapter 23 Setup Relating to Router Interface and Tally (Router/Tally)
1018
Tally Group Settings (Group Tally Menu)
Tally Group Settings (Group Tally Menu)
With the S-Bus protocol, tally control is possible for groups 1 to 8, but in this
system you can use either groups 1 to 4 or groups 5 to 8.
You can also select whether or not to transfer the tally information over the S-
Bus.
To select the tally groups, use the Router/Tally >Group Tally menu.
To display the Group Tally menu
In the Engineering Setup menu, select VF6 ‘Router/Tally’ and HF2 ‘Group
Tally.’
The following functions are available here.
• Tally Group: Select the group tally (Gp1 to 4 or Gp5 to 8) which can be
used. (For the parallel tally, all groups can be used regardless of this setting.)
• S-Bus Tally Enable: Specify S-Bus tally enabled or disabled.
Setting the tally groups
1
To select a consecutive sequence of groups from each of groups 1 to 4 and
groups 5 to 8, set [All Group Enable] to On in the Group Tally menu.
2
In the <Tally Group> group, select the desired groups.
