Chapter 22 DCU Setup (DCU)
992
Settings Relating to Parallel Inputs (Input Config Menu)
This assigns the GPI input, and this is reflected in the status area.
Releasing the Assignment of a GPI Input Port
1
In the DCU >Input Config menu, select what the setting applies to (DCU1
or DCU2) from the <DCU Select> group.
2
In the <Parallel Input Assign> group, if [GPI Input] is on, press it to turn
it off.
3
Turn the knobs to adjust the following parameters.
4
In the <Parallel Input Assign> group, press [No Assign].
Knob Parameter Adjustment Setting values
1 From No First port number 1 to To No
2 To No Last port number From No to 102
To Next Page
